StarTech.com 10m (32.8ft) LC (UPC) OM4 Multimode Fiber Optic Cable, Push Pull Tabs, 50/125, 100G, Low Insertion Loss, Fiber Jumper Cord

Product #: ETLZ1078671959
Sold Out

This product is sold out and we do not know when we will be getting another shipment. We apologize for any inconvenience this may cause.

Check similar items above to see if a replacement product is available.

Product Description

StarTech.com 10m (32.8ft) LC (UPC) OM4 Multimode Fiber Optic Cable, Push Pull Tabs, 50/125, 100G, Low Insertion Loss, Fiber Jumper Cord
10m (32.8ft) OM4 LOMMF LC/LC-UPC Fiber Cable w/Push Pull Tabs; 10/40/100Gbps Full Duplex; 50/125µm Bend-Insenitive Fiber; BW: 4700MHz.km at 850nm; Bend Radius: 6cm (loaded)/3cm (unloaded); OD: 3mm; Jacket: LSZH; Temp Range: -20 to 60C (-4 to 140F)
LC/UPC to LC/UPC OM4 Multimode Fiber Optic Cable enables 40/100G network connections. The push-pull tabs on each connector ensure quick connection and removal, facilitating accurate installation in high connection density environments. The bend-insensitive fiber and molded strain reliefs support cable runs requiring micro/macro bends while maintaining low attenuation. The retractable strain-relief housings enable toolless in-field polarity swapping. Color-coded LC-Duplex connectors ensure error-free polarity configuration.
Engineered for Optimal Performance
Precision-manufactured ceramic ferrules ensure accurate fiber alignment to prevent connectivity issues and minimize insertion loss. Designed for reliability in high-density network applications, the LC to LC UPC polished fiber ends greatly improves return loss characteristics. The Laser-Optimized Multi-Mode Fiber (LOMMF) OM4 fiber patch cable is ideal for 850nm and 1300nm Vertical-Cavity Surface-Emitting Laser (VCSEL) and LED sources.
Compatibility
This multimode 50/125µm fiber optic patch cord is backward compatible with OM3 and 1/10/40G networks, ensuring a reliable connection in legacy fiber environments.
LSZH Cable Jacket
Housed in a LSZH (Low-Smoke, Zero-Halogen) flame-retardant jacket, this OM4 fiber cable emits low smoke and toxic fumes when exposed to extreme heat or in the event of a fire. This enables safer cable installations in areas with poor ventilation including some industrial settings, self-contained environments such as trains and aircraft, as well as residential settings where compliance with building codes must be considered.
Each OM4 fiber cable is also individually tested for insertion loss performance that meets or exceeds the TIA/EIA-568 industry standard, for guaranteed compatibility and 100% reliability.
  • PUSH-PULL OM4 CABLE: OM4 LOMMF Cable is immune to EMI and supports up to 100Gbps networks; Push-pull tab design provides quick access for precise insertion/removal in high-density installations; Retractable connector housings for toolless polarity swapping
  • QUALITY CONSTRUCTION: LC/LC-UPC ends for improved return loss over PC polish; Bend Insensitive fiber core housed in Aramid-reinforced jacket for a loaded bend radius of 6cm and 3cm when unloaded
  • SAFETY AND RELIABILITY: Individually tested for signal integrity; LSZH (Low-Smoke Zero-Halogen) jacket emits low toxic fumes if combusted; Safe for enclosed/poorly ventilated spaces; Attenuation below 2.4dB/km at 850nm meets or exceeds industry standards
  • WIDE COMPATIBILITY: OM4 multimode cable supports 10/40/100G networks; Backward compatible with OM3; High micro-bending resistance facilitates tight bends in intricate environments, ideal for fiber switches/servers, SANs, and SFP+/QSFP+/QSFP28 modules
  • SPECS: 10m (32.8ft); OM4; LC/LC UPC; Push Pull Tabs; 50/125µm; 850nm or 1300nm LED/VCSEL; Modal Bandwidth: 4700MHz/km (850nm); Attenuation: 2.4dB/km (850nm), 0.6dB/km (1300nm); Cable OD: 2.9mm; Bend Radius: 6cm/2.4in (loaded), 3cm/1.2in (unloaded)
  • Provides a simple and efficient way to connect multiple devices within your business network, ensuring smooth communication and reliable data transfer
  • Features fiber optic cable type to deliver high-bandwidth data transmission with minimal signal loss, ensuring optimal performance in network setups
  • Bend Insensitive feature ensures dependable operation and improved usability, delivering consistent performance for everyday connectivity needs
  • LC/UPC Network - Male provides a stable connection with network devices, supporting uninterrupted signal transmission and system integration
Related Articles
Need more information? Ask a Question

Product Specifications

  • Brand Name
    StarTech.com
  • Cable Characteristic
    Patch Cable
  • Cable Length
    32.81 ft
  • Cable Type
    Fiber Optic
  • Connector Type on First End
    LC/UPC Network - Male
  • Connector Type on Second End
    LC/UPC Network - Male
  • Data Transfer Rate
    100 Gbit/s
  • Device Supported
    Network Device Switch Server Module
  • EU RoHS Declaration URL
    https://media.startech.com/cms/pdfs/450fblclc10pp_rohs.pdf
  • End of Life Manual Availability
    Yes
  • Environmental Certification
    EU RoHS
  • Environmental Compliance
    Restriction of Hazardous Substances (RoHS) 2 Registration, Evaluation, Authorization and Restriction of Chemicals (REACH) Waste Electrical and Electronic Equipment Directive (WEEE)
  • Environmentally Friendly
    Yes
  • Features
    Bend Insensitive Bendable Molded Strain Relief UPC Polished Connector Flame Retardant
  • Fiber Optic Cable Core/Cladding Specification
    50/125 µm
  • Fiber Optic Mode
    Multi-mode
  • Jacket Type
    LSZH
  • Manufacturer Part Number
    450FBLCLC10PP
  • Product Name
    Fiber Optic Duplex Patch Network Cable
  • Product Type
    Network Cable
  • REACH Declaration URL
    https://media.startech.com/cms/pdfs/450fblclc10pp_rohs.pdf
  • REACH free of SVHC
    Yes
  • WEEE Statement
    https://media.startech.com/cms/pdfs/450fblclc10pp_weee.pdf
