Eaton Tripp Lite Series 10G Duplex Multimode 50/125 OM4 LSZH Fiber Optic Cable (LC/LC), Push/Pull Tabs, Magenta, 5 m
Product #:
SYNX4766241
+1View All
Product Description
Eaton Tripp Lite Series 10G Duplex Multimode 50/125 OM4 LSZH Fiber Optic Cable (LC/LC), Push/Pull Tabs, Magenta, 5 m
Fiber Optic for Network Device - 12.50 GB/s - Patch Cable - 16.40 ft - 2 x LC Male Network - 2 x LC Male Network - 50/125 µm - Magenta
The N821-05M-MG-T 10 Gb Duplex Multimode 50/125 OM4 LSZH Fiber Patch Cable is OM4-rated for use with 10 Gb Ethernet applications up to 400 meters (at 850 nm). Suited for LANs, SANs and high-speed parallel interconnects for head-ends, central offices and data centers, this low-cost cable provides four times more bandwidth than conventional 62.5 µm multimode fiber and performance rivaling that of singlemode cable.
Push/pull tab connectors are easily accessible in high-density data center applications and make the cable easy to install and remove with one hand. Dual male LC connectors are widely compatible and thoroughly tested to meet stringent insertion loss standards. Premium-grade ceramic ferrules are designed specifically to handle applications of 10 Gb or higher.
Colored magenta for immediate identification as an OM4 cable, the laser-optimized multimode fiber (LOMMF) N821-05M-MG-T is backward compatible with existing 50/125 fiber and commonly used with vertical-cavity surface-emitting laser (VCSEL) and LED laser light sources.
The low-smoke zero-halogen (LSZH) jacket limits the amount of toxic smoke emitted in case of combustion, making this cable perfect for poorly ventilated areas. The slim, space-saving uniboot design is easy to manage through ceilings, walls and ducts. The sturdy plastic housing is built to last a long time.
Features
OM4-Rated for 10 Gb Ethernet Applications
Magenta color for easy OM4 identification
Allows 10 Gb serial transmission up to 400 m (@ 850 nm)
Recommended for LANs, SANs and high-speed parallel interconnects for head-ends, central offices and data centers
Provides 4x more bandwidth than conventional 62.5 µm multimode fiber
Commonly used with VCSEL and LED laser light sources
Backward compatible with existing 50/125 fiber
LC Connectors with Push/Pull Tabs
Push/pull tab connectors easy to install and remove with one hand
Sturdy dual LC connectors tested to meet stringent insertion loss standards
Premium Construction for Error-Free Signal Transfer
Premium-grade ceramic ferrules for 10 GbE and faster applications
Slim, space-saving uniboot design easy to manage through ceilings, walls and ducts
Low-smoke zero-halogen jacket ideal for poorly ventilated areas
Sturdy plastic housing built to last a long time
Meets current IEEE 802.3ae and TIA LOMMF standards
More from the Manufacturer
Push/pull tab connectors are easily accessible in high-density data center applications and make the cable easy to install and remove with one hand. Dual male LC connectors are widely compatible and thoroughly tested to meet stringent insertion loss standards. Premium-grade ceramic ferrules are designed specifically to handle applications of 10 Gb or higher.
Colored magenta for immediate identification as an OM4 cable, the laser-optimized multimode fiber (LOMMF) N821-05M-MG-T is backward compatible with existing 50/125 fiber and commonly used with vertical-cavity surface-emitting laser (VCSEL) and LED laser light sources.
The low-smoke zero-halogen (LSZH) jacket limits the amount of toxic smoke emitted in case of combustion, making this cable perfect for poorly ventilated areas. The slim, space-saving uniboot design is easy to manage through ceilings, walls and ducts. The sturdy plastic housing is built to last a long time.
Features
OM4-Rated for 10 Gb Ethernet Applications
Magenta color for easy OM4 identification
Allows 10 Gb serial transmission up to 400 m (@ 850 nm)
Recommended for LANs, SANs and high-speed parallel interconnects for head-ends, central offices and data centers
Provides 4x more bandwidth than conventional 62.5 µm multimode fiber
Commonly used with VCSEL and LED laser light sources
Backward compatible with existing 50/125 fiber
LC Connectors with Push/Pull Tabs
Push/pull tab connectors easy to install and remove with one hand
Sturdy dual LC connectors tested to meet stringent insertion loss standards
Premium Construction for Error-Free Signal Transfer
Premium-grade ceramic ferrules for 10 GbE and faster applications
Slim, space-saving uniboot design easy to manage through ceilings, walls and ducts
Low-smoke zero-halogen jacket ideal for poorly ventilated areas
Sturdy plastic housing built to last a long time
Meets current IEEE 802.3ae and TIA LOMMF standards
More from the Manufacturer
- Nearly 4x the bandwidth over conventional 62.5 µm multimode fiber
- Push/pull tab connectors install/remove with one hand
- Slim, space-saving uniboot design for neat cable management
- Premium-grade ceramic ferrules designed for fast applications
- Magenta color for easy OM4 identification
- For exceptional quality, upright compatibility and reliability use this network cable
- Features Fiber Optic cable type for your convenience and desired usability
- Uniboot Connector feature for your convenience and ease of usage
- Fully compatible with network devices
Loading...
Product Specifications
-
Brand NameTripp Lite series
-
Cable CharacteristicPatch Cable
-
Cable Length16.40 ft
-
Cable TypeFiber Optic
-
Connector Type on First EndLC Network - Male
-
Connector Type on Second EndLC Network - Male
-
Connector on First End Details2 x LC Network - Male
-
Connector on Second End Details2 x LC Network - Male
-
Country of OriginChina
-
Data Transfer Rate100 Gbit/s
-
Device SupportedNetwork Device
-
Environmental ComplianceRestriction of Hazardous Substances (RoHS)
-
Environmentally FriendlyYes
-
FeaturesHalogen Free Uniboot Connector
-
Fiber Optic Cable Core/Cladding Specification50/125 µm
-
Fiber Optic ModeMulti-mode
-
Limited WarrantyLifetime
-
Manufacturer Part NumberN821-05M-MG-T
-
Product ColorMagenta
-
Product ModelN821-05M-MG-T
-
Product NameN821-05M-MG-T Fiber Optic Network Cable
-
Product TypeNetwork Cable
-
Shipping Height9"
-
Shipping Width7"
