Raritan MasterConsole MCD-LED17116 LCD Rack Console

16 Computer(s) - 17.3" LCD - 1920 x 1080 - 16 x Network (RJ-45)HDMIDVIVGA - 1U High - Black
Product Number: SYNX4940181
  • 1U, small form factor design
  • Single user of control 8 or 16 servers
  • Control up to 512 servers by cascading
  • Support VGA/DVI/HDMI/DP digital video interfaces
More details
Sold Out

This product is sold out and we do not know when we will be getting another shipment. We apologize for any inconvenience this may cause.

Check similar items above to see if a replacement product is available.

Product Description

Raritan MasterConsole MCD-LED17116 LCD Rack Console - CAT5 ANALOG/DIGITAL KVM SWITCH FOR SMALL TO MIDSIZED IT ENVIRONMENTS

Employing state-of-the-art technologies in a compact device, Raritan's MasterConsole Digital KVM switch (MCD) and 17'' LED Console Drawer with integrated KVM switch (MCD-LED) provides reliability, ease of use, and convenience that you need in your data center, lab or server room.

The MCD supports the highest HD video resolution of up to 1920 x 1080 via standard Category 5/6/6e. The digital video interface supports both Analog - VGA and Digital - DVI, HDMI and DisplayPort. Stereo audio is also supported by using VGA combo cables or Raritan's HDMI CIMs.

Building upon Raritan's history of success with KVM switches, the MasterConsole Digital Series is ideal for performing system maintenance, administration, running applications, and troubleshooting.

CONVENIENT KVM ACCESS AT-THE-RACK OR AT YOUR DESK

CONSOLIDATED ACCESS AND CONTROL OF MULTIPLE SERVERS

The MasterConsole Digital Series efficiently consolidates access and control of multiple servers for one or two users. Models are available for KVM connections to 8, 16, or 32 servers.

CASCADE TO ACCESS AND CONTROL UP TO 1024 COMPUTERS

Using standard Category 5/6/6e unshielded twisted-pair (UTP) cables, MasterConsole Digital Series can be cascaded two levels to access up to 1024 computers.

EASY OPERATION AND POWERFUL FUNCTIONALITY

POWERFUL LCD KVM DRAWER FUNCTIONALITY

With a touchpad mouse, simple on-screen user interface and automatic screen power off, the MCD-LED combination LCD Drawer and KVM switch provides complete system management in an intuitive, simple device. Providing an enhanced visual display with 300 nit brightness, and a typical 650:1 contrast ratio, these switches are an investment in high-performing, user-friendly management of your server environment.

A SINGLE SWITCH FOR DIGITAL AND ANALOG VIDEO

MasterConsole Digital switches and consoles support the latest digital video formats (DVI, HDMI and DisplayPort), as well as servers with analog VGA video. In a single switch! Connect to both new and legacy servers with the MasterConsole Digital CIMs and VGA CIM cables. Stereo audio is available for servers with VGA and HDMI video.

EASIER AND MORE INTUITIVE OPERATION

Operation is easier than ever with intuitive, user-friendly features, including:

Own-screen user interfaces and the front panel of the switch allow for simple set-up, control, and management
Front panel LEDs allow for instant monitoring of server statuses
On-screen display (OSD) interface enables fast and easy switching
Computers can be labeled with meaningful names for quick identification and selection
OSD menus can be operated with keyboard hot keys
Password security ensures only authorized access to computers INDUSTRY LEADING SCALABILITY AND PERFORMANCE

Designed to provide maximum flexibility and versatility:

KVM switches can be cascaded to control up to 1024 servers at distances up to 150 feet
AutoSkip function bypasses inactive channels, while AutoScan function previews servers at variable rates
"Keep-alive" technology maintains non-stop server operation, even in the event of power loss
MCD KVM switches are firmware upgradeable and rack mountable

  • 1U, small form factor design
  • Single user of control 8 or 16 servers
  • Control up to 512 servers by cascading
  • Support VGA/DVI/HDMI/DP digital video interfaces
  • Widescreen resolution support up to 1920 x 1080
Related Articles
 Need more information? Ask a Question

Product Specifications

  • Brand Name
    Raritan
  • Country of Origin
    Taiwan
  • DVI
    Yes
  • Depth
    22.5"
  • DisplayPort
    Yes
  • Display Screen Type
    LCD
  • HDMI
    Yes
  • Height
    1.7"
  • Input Voltage Range
    100V AC to 240V AC
  • Manufacturer Part Number
    MCD-LED17116
  • Network (RJ-45)
    Yes
  • Number of Computers Supported
    16
  • Number of Network (RJ-45) Ports
    16
  • Power Consumption
    65 W
  • Product Color
    Black
  • Product Line
    MasterConsole
  • Product Model
    MCD-LED17116
  • Product Name
    MasterConsole MCD-LED17116 LCD Rack Console
  • Product Type
    LCD Rack Console
  • Rack Height
    1U
  • Screen Resolution
    1920 x 1080
  • Screen Size
    17.3"
  • VGA
    Yes
  • Width
    18.9"
