Zyxel WiFi 6E AXE5400 2.5G Multi-Gigabit Business AP | Bandflex 2.4Ghz and 5Ghz or 6Ghz Operation | 1 GbE Passthru| Mesh, Seamless Roaming, Captive Portal | Hybrid Cloud | POE+ Support | WAX620D-6E
Product #:
ETLZ1073998466
Sold Out
This product is sold out and we do not know when we will be getting another shipment. We apologize for any inconvenience this may cause.
Check similar items above to see if a replacement product is available.
Product Description
Zyxel WiFi 6E AXE5400 2.5G Multi-Gigabit Business AP | Bandflex 2.4Ghz and 5Ghz or 6Ghz Operation | 1 GbE Passthru| Mesh, Seamless Roaming, Captive Portal | Hybrid Cloud | POE+ Support | WAX620D-6E
2.40 GHz, 5 GHz, 6 GHz - 6 x Internal Antenna(s) - Internal - MIMO Technology - 2 x Network (RJ-45) - Gigabit Ethernet, 2.5 Gigabit Ethernet - Wall Mountable, Ceiling Mountable, T-bar Mount - 1 Pack
Featuring 6 spatial streams (4x4 in 6 GHz/5 GHz selectable, 2x2 in 2.4 GHz) with the maximum data rate of 5.4 Gbps, the Zyxel WAX620D-6E is the dual-radio access point with a BandFlex radio that can support either 5 GHz or 6 GHz by configuration, making it the most economical choice to fit into your existing 5 GHz coverage as well as futureproofing the use of 6 GHz.
WAX620D-6E includes all the benefits of WiFi 6 capabilities like OFDMA, MU-MIMO, BSS Coloring, and brings them into the brand-new, interference-free 6 GHz that more than doubles the WiFi capacity to deliver multi-gigabit speed, and low-latency connections.
The brand-new, interference-free 6GHz band presents a solution to quenching the thirst for today's network hungry for more bandwidth, making it a perfect choice for high-density WiFi and emerging technology connectivity. To reach the full potential of the new band, Zyxel 6E Boost, using the high-gain 4x4 streams in 6 GHz, increases the maximum gains in transmit beamforming and receive MIMO to extend its range and ensure the highest performance is delivered.
The WAX620D-6E is ideal in high density environments such as transport hubs, exhibition halls, schools, offices, hotels, restaurants, or any other organizations that need to accommodate a large number of devices as it can offer the optimal premium service for everyone, every time they connect to WiFi.
Benefits | WiFi 6E - bringing WiFi 6 into 6 GHz spectrum
WiFi 6E is the WiFi 6 extended into 6 GHz spectrum. It includes all the WiFi 6 features, plus the following:
2.5X More Capacity: 2.5 times more spectrum with the extended 6 GHz band with no legacy devices
Superwide Channels: Utilizing up to seven additional superwide 160 MHz channels in 6 GHz for bandwidth-demanding applications like VR/AR, WiFi calling, and high-definition video streaming
No Interference: No interference from microwaves and the non-6E devices. Only Wi-Fi 6E capable devices can use the 6 GHz band. Superior performance with innovative "Dual-optimized" antenna
People without RF expertise may not realize that installing an AP optimized for ceiling-mount as wall-mount may cause the ceiling-mount radiation pattern to interfere with other devices up- or downstairs as well as to deliver signals with shorter-than-expected range for its clients. Designed with the innovative "Dual-optimized" antenna, the WAX620D-6E adapts to both wall- and ceiling-mount installations. Thus, users can switch between the two optimized antenna modes easily to fit either situation. To boost WiFi speeds for your network, the WAX620D-6E is definitely an excellent choice.
WAX620D-6E includes all the benefits of WiFi 6 capabilities like OFDMA, MU-MIMO, BSS Coloring, and brings them into the brand-new, interference-free 6 GHz that more than doubles the WiFi capacity to deliver multi-gigabit speed, and low-latency connections.
The brand-new, interference-free 6GHz band presents a solution to quenching the thirst for today's network hungry for more bandwidth, making it a perfect choice for high-density WiFi and emerging technology connectivity. To reach the full potential of the new band, Zyxel 6E Boost, using the high-gain 4x4 streams in 6 GHz, increases the maximum gains in transmit beamforming and receive MIMO to extend its range and ensure the highest performance is delivered.
The WAX620D-6E is ideal in high density environments such as transport hubs, exhibition halls, schools, offices, hotels, restaurants, or any other organizations that need to accommodate a large number of devices as it can offer the optimal premium service for everyone, every time they connect to WiFi.
Benefits | WiFi 6E - bringing WiFi 6 into 6 GHz spectrum
WiFi 6E is the WiFi 6 extended into 6 GHz spectrum. It includes all the WiFi 6 features, plus the following:
2.5X More Capacity: 2.5 times more spectrum with the extended 6 GHz band with no legacy devices
Superwide Channels: Utilizing up to seven additional superwide 160 MHz channels in 6 GHz for bandwidth-demanding applications like VR/AR, WiFi calling, and high-definition video streaming
No Interference: No interference from microwaves and the non-6E devices. Only Wi-Fi 6E capable devices can use the 6 GHz band. Superior performance with innovative "Dual-optimized" antenna
People without RF expertise may not realize that installing an AP optimized for ceiling-mount as wall-mount may cause the ceiling-mount radiation pattern to interfere with other devices up- or downstairs as well as to deliver signals with shorter-than-expected range for its clients. Designed with the innovative "Dual-optimized" antenna, the WAX620D-6E adapts to both wall- and ceiling-mount installations. Thus, users can switch between the two optimized antenna modes easily to fit either situation. To boost WiFi speeds for your network, the WAX620D-6E is definitely an excellent choice.
- 802.11axe AP (4x4 in 6 GHz/5 GHz selectable, 2x2 in 2.4 GHz) to deliver maximum data rate of 5.4 Gbps
- The BandFlex radio design can support either 5 GHz or 6 GHz by configuration, to fit into your 5 GHz coverage as well as futureproofing the use of 6 GHz
- Zyxel 6E Boost, using the high-gain 4 streams in 6 GHz, helps extend range and maximize performance of the new band
- Dual-optimized antenna provides the optimum radio patterns for both wall and ceiling mounting to fit into your installation
- NebulaFlex Pro offers the full flexibility for users to easily switch between Nebula cloud-managed, controller-managed, and standalone modes
- Create a reliable wireless business network with this wireless access point that features a high-speed data transfer rate
- 5.40 Gbit/s wireless transmission speed provides better reception, and dependable connectivity with maximum productivity
- IEEE 802.11 a/b/g/n/ac/ax wireless LAN standard lets you connected on the go so your productivity never stops
- Gigabit Ethernet Ethernet technology for increasing efficiency with the quicker transfer and sharing of information
- Data Encryption provides reliable and enhanced data security and management
- Internal antenna form factor for reliable connectivity with maximum productivity
- Wall Mountable form factor offers comfortable usage for a longer duration
Product Specifications
-
Antenna Form FactorInternal
-
Brand NameZYXEL
-
Certifications & StandardsFCC Part 15C FCC Part 15E ETSI EN 300 328 EN 301 893 EN 303 687 LP0002 FCC Part 15B EN 301 489-1 EN 301 489-17 EN 55022 EN 55024 EN 60601-1-2 BSMI CNS 13438 Safety EN 62368 BSMI CNS 14336-1
-
Communication ProtocolsRADIUS SNMP
-
Country of OriginChina
-
Depth7.1"
-
Encryption StandardWEP WPA WPA2 WPA2-PSK WPA3 WPA3-ENT
-
Environmental ComplianceRestriction of Hazardous Substances (RoHS)
-
Environmentally FriendlyYes
-
Ethernet Technology2.5 Gigabit Ethernet Gigabit Ethernet
-
Form FactorCeiling Mountable T-bar Mount Wall Mountable
-
Frequency Band2.40 GHz 5 GHz 6 GHz
-
Height1.7"
-
Indoor/OutdoorIndoor
-
MIMO TypeMulti User MIMO
-
Manufacturer Part NumberWAX620D-6E
-
Network BandTri Band
-
Number of Internal Antennas6
-
Number of Network (RJ-45) Ports2
-
Package ContentsAXE5400 WiFi 6E Dual-Radio Access Point Mount Plate Mounting Screws
-
Product ModelWAX620D-6E
-
Product NameAXE5400 WiFi 6E Dual-Radio Access Point
-
Product TypeWireless Access Point
-
Total Number of Antennas6
-
Width7.1"
-
Wireless LAN StandardIEEE 802.11 a/b/g/n/ac/ax
-
Wireless PerformanceAXE5400
-
Wireless Transmission Speed5.40 Gbit/s
