IOGEAR GCS1716KITU KVM Switch

16 Computer(s) - QXGA - 2048 x 1536 - 1 x USB - Rack-mountable - 1U
Product Number: SYNX2883209
  • Multi platform OS support - Windows, Mac, Sun Solaris , and Linux
  • Auto Scan Mode to monitor connected computers
  • Broadcast Mode to send commands to all connected computers
  • Easy to operate - computer selection via front panel LED's, intuitive OSD (on screen display), and hotkeys
More details
Sold Out

This product is sold out and we do not know when we will be getting another shipment. We apologize for any inconvenience this may cause.

Check similar items above to see if a replacement product is available.

Product Description

IOGEAR GCS1716KITU KVM Switch - The GCS1716KITU KVM is a combo switch with USB KVM cables included; allowing access and control of up to 16 directly connected computers from a single console (keyboard, mouse, and monitor). As many as 16 additional switches can be cascaded bringing the total number of connected computers to 256 computers that can be controlled from a single keyboard-monitor-mouse console. A custom ASIC (patent pending) provides an auto-sensing function that recognizes the position of each station on the installation, eliminating the need to manually set the position with DIP switches. Additionally, the GCS1716 features high density SPHD 15-pin instead of the usual 25-pin connectors thus allowing for a compact design and installation in a 1U system rack.
More from the Manufacturer

  • Multi platform OS support - Windows, Mac, Sun Solaris , and Linux
  • Auto Scan Mode to monitor connected computers
  • Broadcast Mode to send commands to all connected computers
  • Easy to operate - computer selection via front panel LED's, intuitive OSD (on screen display), and hotkeys
  • *Cascade up to 2 levels - control up to 256 computers from a single console
  • Security - 2 level password protection for OSD
  • Maximum video resolution: up to 2048 x 1536
  • Supports both USB and PS/2, VGA computers
  • ** Front USB Port - Fully compliant with USB 1.1 for system upgrades and shared peripherals
  • Rack mountable in a 19" (1U) system rack
  • Use this KVM Switchbox and eliminate the need for manually switching cables between sources
  • Get high-resolution video with impressive clarity, thanks to the 2048 x 1536 resolution.
  • KVM Switchbox can be mounted as rack-mountable
Related Articles
 Need more information? Ask a Question
Read More

Product Specifications

  • Brand Name
    IOGEAR
  • Country of Origin
    China
  • Daisy Chain Supported
    Yes
  • Depth
    6.3"
  • Environmentally Friendly
    Yes
  • Form Factor
    Rack-mountable
  • Graphic Mode
    QXGA
  • Height
    1.8"
  • Input Voltage
    5.3 V DC
  • Limited Warranty
    3 Year
  • Manufacturer Part Number
    GCS1716KITU
  • Maximum Video Resolution
    2048 x 1536
  • Number of Computers Supported
    16
  • Number of USB Ports
    1
  • Package Contents
    GCS1716KITU KVM Switch 1 x 2m USB KVM Cable 1 x 2m PS/2 KVM Cable 16 x 3m USB KVM Cable 1 x Console Cable 1 x Cascade Cable 1 x Firmware Upgrade Cable 1 x Grounding Wire 1 x Foot Pad Set 1 x Power Adapter 1 x Installation Guide 1 x Warranty Card 1 x Standard Rack Mounting Kit
  • Product Model
    GCS1716KITU
  • Product Name
    GCS1716KITU KVM Switch
  • Product Type
    KVM Switchbox
  • Rack Height
    1U
  • USB
    Yes
  • Width
    17"
