Tripp Lite by Eaton Rackmount KVM Switch 4-Port / USB / PS2 w/ On-Screen Display 1U
Product #:
SYNX2093571
Product Description
Tripp Lite by Eaton Rackmount KVM Switch 4-Port / USB / PS2 w/ On-Screen Display 1U
4 x 11U - Rack-mountable
Tripp Lite's NetController 4-Port, 1U rackmount KVM Switch is an affordable, highly-flexible enterprise class KVM Switch, which allows the user to connect either USB or PS/2 keyboards and mice. In addition, P780-Series USB/PS2 combo KVM cable kits allow you to connect either USB or PS/2 computers, without the need to purchase separate cables or adapters. Control up to 4 directly connected computers, or expand the number of connected computers to up to 244 by daisychaining up to 15 additional B042-Series KVM switches. Switch between connected computers via the On-Screen Display (OSD), pushbuttons, or keyboard hotkey commands. Other features include: password protection, auto-scanning, auto-logout, firmware upgrade and video support up to 2048 x 1536 (QXGA). Mounts easily in a standard 19" rack/cabinet and includes all necessary mounting hardware. Compatible with all major operating systems. Constructed of heavy-duty steel housing. 3 year limited warranty.
More from the Manufacturer
More from the Manufacturer
- NetController 4-Port, 1U rackmount KVM switch
- Control 4 computers via a single VGA monitor and USB or PS/2 keyboard/mouse
- Control up to 244 computers by daisychaining up to 15 additional B042-Series KVM switches
- P780-Series USB/PS2 combo KVM cables kits allow you to connect either USB or PS/2 computers, without the need to purchase separate cables or adapters
- Compatible with all major operating systems
- Quickly switches between sources without physical access
- 2048 x 1536 resolution for high-quality video delivery
- Hot-pluggable USB interface for a quick connection
- Designed to be used as a rack-mountable
Loading...
Product Specifications
-
Brand NameTripp Lite series
-
Country of OriginChina
-
Daisy Chain SupportedYes
-
Depth6.5"
-
Environmentally FriendlyYes
-
Form FactorRack-mountable
-
Graphic ModeQXGA
-
Height1.8"
-
Input Voltage230 V AC
-
Limited Warranty3 Year
-
Manufacturer Part NumberB042-004
-
Maximum Video Resolution2048 x 1536
-
Number of Computers Supported4
-
Number of PS/2 Ports2
-
Number of USB Ports1
-
Number of VGA Ports1
-
PS/2 PortYes
-
Package ContentsRack Mount Hardware 8 In Daisy Chain Cable Daisy Chain Terminator 4 ft HD15 to DB9 Firmware Upgrade Cable CD with Owner's Manual and Quick Start Guide External Power Supply NetController KVM Switch Quick Start Guide
-
Product LineNetController
-
Product ModelB042-004
-
Product NameNetController KVM Switch
-
Product TypeKVM Switchbox
-
Rack Height1U
-
USBYes
-
VGAYes
-
Width16.1"
