Transition Networks Mini Gigabit Ethernet Media Converter

Product #: ETLZ1053980043
$268.28
Ships Free - This items ships free with your order
Delivered by Mon 12/15 Tue 12/16 - This is an estimated delivery timeline
Non-returnable - This is a non-returnable item

Product Description

Transition Networks Mini Gigabit Ethernet Media Converter
1 x Network (RJ-45) - 1 x LC Ports - DuplexLC Port - Multi-mode - 0 mil Fiber - Gigabit Ethernet - 1000Base-SX, 10/100/1000Base-T - 0.55 km - AC Adapter - Wall Mountable
The M/GE-T Series is a Gigabit Ethernet stand-alone Mini media converter that provides cost effective, entry-level media conversion between 1000Base-T ports and 1000Base-SX/LX ports. With its fixed configuration, deployments are just plug-and-play, and with its small size, it is ideal for locations where space is limited. Operating at Layer 1, the physical layer, data is passed through the converter at line speed, making it ideal for applications where low latency is essential.
  • Auto-Negotiation
  • Auto-MDI/MDIX
  • Automatic Link Restoration
  • Interoperable with other 1000Base-T/SX/LX NICs or switch ports
  • Status LEDs for easy monitoring
  • Supports SFP modules
  • Supports Jumbo Frames up to 13312bytes
  • 65% smaller than standard media converter
  • Extend Network Distance
  • Low-Latency Design
  • With Twisted Pair cable, get the desired data transfer rate up to a required distance
  • Meet the multiple network connectivity needs of today's network environment with this 2 transceiver/media converter
  • With 1000Base-SX technology get up to 1000Mbps data transfer rate over twisted pair cable
  • Tuck the device out of the way with its Wall Mounting feature
Guides & Information
Related Articles
Need more information? Ask a Question

Product Specifications

  • Additional Information
    1000Base-T (RJ-45) [100m/328 ft.] to 1000Base-SX 850nm multimode (LC)[62.5/125 µm fiber: 220 m/722 ft.] [50/125µm fiber: 550 m/1804 ft.] Link Budget: 8.5 dB
  • Application/Usage
    Data Network
  • Brand Name
    Transition Networks
  • Certifications & Standards
    Safety: Wall Mount Power Supply, UL Listed, cUL Listed (Canada), FCC Class A, CISPR22 / EN55022 Class A, EN55024, CE Mark
  • Country of Origin
    Taiwan
  • Depth
    3.3"
  • Environmental Compliance
    Restriction of Hazardous Substances (RoHS) Waste Electrical and Electronic Equipment Directive (WEEE)
  • Environmentally Friendly
    Yes
  • Ethernet Technology
    Gigabit Ethernet
  • Fiber Mode Supported
    Multi-mode
  • Fiber Optic Cable Core/Cladding Specification
    50/125 µm 62.5/125 µm
  • Fiber Optic Cable Wavelength
    850 nm
  • Form Factor
    Wall Mountable
  • Height
    0.9"
  • Input Voltage
    12 V DC
  • LC Port Type
    Duplex
  • Limited Warranty
    Lifetime
  • Manufacturer Part Number
    M/GE-T-SX-01(LC)-NA
  • Maximum Data Transfer Rate
    1000 Mbit/s
  • Maximum Distance Supported
    0.55 km
  • Media Type Supported
    Optical Fiber Twisted Pair
  • Network (RJ-45)
    Yes
  • Network Technology
    10/100/1000Base-T 1000Base-SX
  • Number of LC Ports
    1
  • Number of Network (RJ-45) Ports
    1
  • Package Contents
    Mini Gigabit Ethernet Media Converter Power Supply
  • Power Consumption
    2.60 W
  • Power Source
    AC Adapter
  • Product Model
    M/GE-T-SX-01(LC)
  • Product Name
    Mini Gigabit Ethernet Media Converter
  • Product Series
    M/GE-T
  • Product Type
    Transceiver/Media Converter
  • TAA Compliant
    Yes
  • Total Number of Ports
    2
  • Width
    1.8"
