Eaton Tripp Lite Series Isobar 12-Outlet Network Server Surge Protector, 15 ft. (4.57 m) Cord with L5-20P Plug, 3840 Joules, Diagnostic LEDs, 1U Rackmount
Product #:
SYNX303927
+1View All
Sold Out
This product is sold out and we do not know when we will be getting another shipment. We apologize for any inconvenience this may cause.
Check similar items above to see if a replacement product is available.
Product Description
Eaton Tripp Lite Series Isobar 12-Outlet Network Server Surge Protector, 15 ft. (4.57 m) Cord with L5-20P Plug, 3840 Joules, Diagnostic LEDs, 1U Rackmount
Receptacles: 12 x NEMA 5-20R - 3840J
Tripp Lite's IBAR12-20T offers network-grade surge and noise suppression in a versatile all-metal multi-mount cabinet with L5-20P twist-lock input plug and 20-amp capacity. Detachable mounting flanges are configurable for rackmount, wallmount and under-counter installation. Uses only 1 rack space (1U) when installed in any 19 inch EIA standard rack. Features network grade AC surge suppression with EMI/RFI noise filtering. Outlets are arranged in exclusive isolated filter banks to limit noise interaction among connected items. Includes 12 outlets (2 front mounted 15-amp/10 rear mounted 20- amp), 15 ft. power cord and power switch. Diagnostic LEDs indicate AC present, line fault and protection status.
More from the Manufacturer
More from the Manufacturer
- 12 outlets - 2 front mounted/10 rear mounted
- 15-ft. cord
- 3840 joule rating
- All metal housing with LEDs
- Adjustable rackmount hardware
- $25,000 Ultimate Lifetime Insurance (U.S., Canada, and Puerto Rico only)
- Safeguards your equipment from the sudden jolts of electricity
- 12 x NEMA 5-20R receptacles to protect your equipment from transient surges
- Give your devices maximum protection with 3840 J energy rating
- Easily connect to a wall outlet with 15 ft cord
Product Specifications
-
Additional InformationVersatile all-metal cabinet with detachable mounting flanges allows rackmount, wallmount, undercounter and other creative mounting options Uses one rack space (1U) in standard 19 inch rack ("zero U" mounting possible in many racks) 1280 joules / 60,000 amp network-grade AC surge suppression with EMI/RFI filtering 12 output receptacles outlets (2 front mounted NEMA 5-15R / 10 rear mounted NEMA 5-20R) 15 foot AC cord with NEMA L5-20P straight-in plug connection Diagnostic LEDs confirm proper wiring and suppressor operation Front panel switch controls power to all outlets 20 amp electrical capacity with circuit breaker 120VAC, 50/60Hz electrical compatibility Lifetime product warranty $25,000 Ultimate Lifetime Insurance (USA & Canada Only)
-
Brand NameTripp Lite series
-
Certifications & StandardsUL1449 (UR status), UL1283, cUL, Exceeds IEEE 587 category A&B specifications
-
CompatibilityTYPICAL APPLICATIONS: Ideal for the protection of sensitive electronic equipment in 19 inch rackmount, wallmount and under-counter applications, such as internetworking equipment, PC systems, telecommunications, audio / video, security, sound reinforcement and more.
-
Country of OriginPhilippines
-
Depth4"
-
Height1.8"
-
Input Voltage120 V AC
-
Limited WarrantyLifetime
-
Manufacturer Part NumberIBAR12-20T
-
Output Voltage120 V AC
-
Package ContentsIBAR12-20T IBAR12-20T Surge Suppressor Warranty information Instruction manual
-
Plug/Connector TypeYes
-
Product NameIBAR12-20T
-
Product TypeSurge Suppressor/Protector
-
Protection TypeSurge
-
Receptacles12 x NEMA 5-20R
-
Status IndicatorsLine OK Line fault Protection present
-
Surge Energy Rating3840 J
-
Width17.5"
